Your page: Home » Products » Low Bed Semi Trailer
★★Frame bed bearing surface is low, suitable for a variety of construction machinery, large equipment transport ★★Reasonable structure: Optimized by advanced computer-aided design system. ★★Advanced technology: Longitudinal beams use low-alloy steel by automatic submerged arc welding machine. ★★We can design the products according to customer’s request.
|
Model |
SZM9400TDP Semi Trailer |
|
Outside Dimension(mm) |
13750,13500,12998x2800,3000x1750,1700,1650,1600 |
|
Cargo Semi Trailer(mm) |
xx |
|
Total weight(kg) |
40000 |
|
Rated Load(kg) |
33800,33500,33200 |
|
Tare Weight(kg) |
6200,6500,6800 |
|
Saddle Bearing Weight(kg) |
16000 |
|
Rear overhang（mm） |
2380,2280,2130,2080 |
|
Departure Angle(°) |
12,13,14,15 |
|
Axles load(kg) |
24000 （3x Axles） |
|
ABS |
Anti-lock braking system |
|
Axle Quantity |
3 |
|
Wheel Base |
7300+1310+1310,7250+1310+1310,7000+1310+1310,6800+1310+1310 |
|
Tyre Quantity |
12 |
|
Tyre specification |
8.25R20 16PR, 8.25-20 16PR |
|
Wheel Track(mm) |
1840/1840/1840, 2180/2180/2180 |
|
Leaf Spring |
-/3/3/3,-/4/4/4,-5/5/5,-/7/7/7,-/8/8/8, -/10/10/10 |
