Characters:
1,It adopts the non-lubricated swing air compressor produced by the domestic first-class auto parts manufacturers.Small size, light weight, matching speed, easy to install on the car; large displacement, oil-free gas; can adapt to dust environment and field environment, reliable and basically maintenance-free.
2,The internal fluidized bed of the tank adopts the "W" or "WV" double warehouse, the internal chute angle is large, which increases the effective volume of the tank, and greatly increases the lower ash speed and reduces the residual ash rate.
3,The cans and metal accessories are shot blasted, sprayed with polymer primer and quality topcoat, strong adhesion, good corrosion resistance, uniform air grinding, long-lasting color, and can withstand adverse environments such as moisture, dust and salt spray. will not problems for cracking, peeling, fading, etc., improves the aesthetics , prevents corrosion.
|
Truck Name |
Powder Material Truck |
Powder Material Truck |
Powder Material Truck |
|
Model |
SZM9402GXH |
SZM9401GXH |
SZM9400GXH |
|
Outside Dimension (L x W x H)(mm) |
10850,10000x2500x4000 |
13000, 12200x2500x4000, |
12200,11400x2500x4000 |
|
Rated Load(kg) |
30300,31100 |
28900,29700 |
30000,30800 |
|
Axle Quantity |
3 |
3 |
3 |
|
Tyre Quantity |
12 |
12 |
12 |
|
Tyre Specification |
11.00R20 12PR, 12R22.5 12PR, 11R22.5 12PR |
11.00R20 12PR, 12R22.5 12PR, 11R22.5 12PR |
11.00R20 12PR, 12R22.5 12PR, 11R22.5 12PR |
|
Leaf Spring |
-/8/8/8,-/10/10/10,-/12/12/12,-/13/13/13, |
-/8/8/8,-/10/10/10, -/12/12/12,-/13/13/13, |
-/8/8/8,-/10/10/10, -/12/12/12,-/13/13/13, |
